C52 Replacement V Belt 7/8 x 56in
C52 Replacement V Belt 7/8 x 56in
Couldn't load pickup availability
One New Aftermarket Replacement Classical C-Section V-Belt - C52 (7/8" x 56" Outside Circumference)
This C52 classical wrapped V-belt is a heavy-duty power transmission belt widely used in agricultural machinery, industrial drives, HVAC systems, conveyor systems, centrifugal pumps, and air compressor applications. The V-shaped cross-section wedges into sheave grooves to maximize friction and power transfer efficiency.
Specifications
- Belt Section: C (Classical)
- Top Width: 7/8 in (0.875 in)
- Belt Depth: 17/32 in (0.531 in)
- Inside Length: 52 in
- Outside Circumference: 56 in
- Reinforcing Cord Material: Polyester
- Construction: Classical wrapped (smooth)
Compatible Applications
The C52 is a standard industry designation belt suitable for use as a single-belt drive or in matched multi-belt sets for higher horsepower requirements. Compatible with agricultural equipment, farm machinery, industrial power transmission drives, HVAC equipment, pumps, and conveyors requiring a C-section belt with a 56-inch outside circumference.
Replaces Part Number(s):
C52
Aftermarket Interchange Numbers
C52, C-52, C 52, CP52, BTQ-C52
New aftermarket replacement part - not remanufactured, not used.
