ELV40-0685 - Generator

One New Aftermarket Replacement Starter-Generator for E-Z-GO (EZGO) Golf Carts and Utility Vehicles

This aftermarket starter-generator is a direct replacement for the Hitachi unit used on E-Z-GO 4-cycle gas golf carts and utility vehicles. The starter-generator serves a dual function -- it cranks the engine to start it and then switches to generator mode to charge the 12-volt battery system while the cart is running.

Specifications

• Voltage: 12V
• Amperage: 15 Amps
• Rotation: Bi-directional (reversible)
• Overall Length: 221.7 mm / 8.728 in
• Field Housing OD: 113.6 mm / 4.472 in
• Shaft OD: 16 mm (threaded)
• Terminals: 5-terminal configuration
• OEM Unit Type: Hitachi

Compatible Models

E-Z-GO Golf Carts: Medalist (1993-2008), TXT 4 Caddy (1998-2008), TXT Fleet (1998-2008), TXT Freedom (1998-2008), TXT Freedom HP (1998-2008), TXT Models (1980-1993), GXI-875 (1994-2008), GXI-875P (1994-2008), GXT-875 (1994-2008), GXT-875P (1994-2008), BC-960GX (1994-1998), PC-952GX (1994-1998), PC-954GX (1994-1998), PC-956GX (1994-1998), Grand Oasis (1994-1998), Oasis (1996-1997)

E-Z-GO Utility and Turf Vehicles: Cargo Shuttle, Industrial 800 (1999-2008), MG2 4 Caddy (1998-2008), MG2 Fleet (1998-2008), MG2 Freedom (1998-2008), MG2 Freedom HP (1998-2008), MPT 800 (2003-2008), MPT 1200 (2003-2008), Shuttle 2 (2005-2008), Shuttle 4/6 (1996-2008), Shuttle 6, Shuttle 950 Series (1994-2004), ST 350 (1998-2008), ST 480 (2000-2008), ST Express (2008-2010), Workhorse 800 (1994-2008), Workhorse 800 LX (1994-2008), Workhorse 1200 (1994-2008), Workhorse 1200 LX (1994-2008)

Replaces Part Number(s):

114-01-4010, 25533-G01, 26993-G01, 27065-G01

Aftermarket Interchange Numbers

Hitachi: GSB107-10B, GSB107-10C; Advanced Motors and Drives: 114-01-4010A, 114-01-4008, 114-01-4002; Clark: 067005319; EZ-GO: 612028, 625715, 649711; Redhawk: MOT-2003; 15423, 15423N

New aftermarket replacement part - not remanufactured, not used.
