ELL70-0343 - Stator
ELL70-0343 - Stator
Couldn't load pickup availability
One New Aftermarket Replacement Stator for Polaris ATV and UTV Models
This aftermarket magneto stator is a direct-fit replacement for the charging system on Polaris ATVs and UTVs. The stator generates AC current that is converted by the regulator/rectifier to power the electrical system and charge the battery. Multiple stator designs exist for these models -- please validate this part number (3084974) against your original unit before ordering, and compare wire count and connector configuration to confirm fitment.
Specifications
- Interior diameter: 42 mm
- Exterior diameter: 105 mm
- Thickness: 32 mm
- Number of wires: 9
- Number of plugs: 7 | Number of pins: 12
- Alternator resistance (Yellow to Yellow/Red): 0.4 ohms +/-20%
- Pickup resistance (White/Red to White): 115 ohms +/-20%
- Source resistance (Black/Red to Green): 450 ohms +/-20%
- Source 2 resistance (Red to Green): 4.1 ohms +/-20%
Compatible Models
Polaris ATV (Magnum): Magnum 425 2x4 (1995-1998), Magnum 425 4x4 (1995-1998), Magnum 425 6x6 (1996-1997)
Polaris ATV (Sportsman): Sportsman 335 (1999-2000), Sportsman 400 (2001-2002), Sportsman 500 4x4 (1996-1997)
Polaris ATV (Worker / Xplorer): Worker 335 (1999), Xplorer 500 4x4 (1997)
Polaris UTV (Ranger): Ranger 425 2x4 (2001), Ranger 425 2x4 (2002, built before 8/09/02), Ranger 500 (1995-2004)
Replaces Part Number(s):
3084974, 3086860
Aftermarket Interchange Numbers
Rick's Motorsport Electricals: 21-553, 21553; ELL70-0343
New aftermarket replacement part - not remanufactured, not used.
