AR78825 Two Red LED Warning Tail Lights Fits John Deere 30 40 50 and White

Name: AR78825 Two Red LED Warning Tail Lights Fits John Deere 30 40 50 and White
SKU: ELJ50-0335_x2
Price: 144.0 USD
Availability: InStock

AR78825 Two Red LED Warning Tail Lights Fits John Deere 30 40 50 and White

$144.00 CAD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

Two New Aftermarket Replacement Red LED Lights Fits John Deere Tractor Models: 30, 40, 50 Series

Will Also Fit Various White Tractor Models.

Tech Info:

This lamp requires the black ground wire eyelet to be grounded properly for light to function. It may be connected to the existing light mounting screws with an internal tooth lock washer & nut or to the fender panel with a self-tapping screw. (hardware not included with light)
Red Polycarbonate Lens
3 - 3 Watt LED Lights
Black wire ground, red wire high beam, white wire low beam
Can wire for Hi / Low (Brake Light) function
Mount: 4 mounting holes 4" apart side to side & 3" apart top to b

Models This Part Fits:

5730, 9130, 7445, 2-180 SERIES II, 160, 4030, 2-135, 5410, 9170, 500B, 4960, 2140, 4555, 8450, 4440, 6500, 4455, 2855N, 8440, 484, 4000, 5830, 4560, 6030, 2-75, 4020, 9910, 2755, 4230, 4630, 8650, 100, 8630, 2940, 5440, 2510, 5210, 4640, 5020, 2-105, 4520, 7020, 7440, 2-70, 9960, 2-78, 2-88, 6100, 5310, 5510, 4055, 9930, 3040, 2-180, 8640, 4320, 2355, 4040, 4240, 9190, 4755, 2950, 2555, 2955, 3150, 9965, 4620, 4250, 5720, 4840, 7520, 4850, 9920, 4-270, 6600, 9150, 2550, 2-110, 2-155, 4430, 3055, 8850, 8430, 6000 HI-CYCLE, 2-115, 3020, 9970, 3155, 4050, 9950, 2750, 3255, 4650, 4450, 140, 120, 4255, 185, 2-85, 2-150, 9940, 5820, 4760, 9900, 4955, 2350, 5460, 3140

Additional Information:

Oval 4 Mounting Holes 4" Apart Side to Side & 3" Apart Top to Bottom 7.900" Overall Length 3.600" Top to Bottom (3) 3 Watt Led Lights 6 - 30 Volt Systems Black Wire Is Ground, Red Wire Is High Beam, Yellow Wire Is Low Beam Note: the Black Wire Must Be Grounded Properly for the Light to Function.
