45LS Spark Plug for Universal Products

45LS Spark Plug for Universal Products

$49.00 CAD
$49.00 CAD
Sale Sold out
Shipping calculated at checkout.

One New Aftermarket Replacement Spark Plug - AC Fits Delco 45LS / Fits Champion RH18Y Cross-Reference

This aftermarket replacement spark plug is a direct cross-reference for AC Fits Delco 45LS, Fits Champion RH18Y (stock number 857), and a wide range of OEM numbers from Motorcraft, Fits NGK, Fits Bosch, and Fits Denso. It is a resistor-type plug with a flat/gasket seat and extended projected tip, suited for small engines found in lawn and garden tractors, garden equipment, and light utility machines. Compatible applications include Onan-powered equipment from Fits Case, Bolens, Fits Craftsman/Sears, and similar brands.

Specifications

  • Thread Diameter: 14mm (0.551")
  • Hex Size: 21mm (0.826")
  • Reach: 11.2mm (0.437")
  • Seat Type: Flat/Gasket
  • Tip Configuration: Extended Projected
  • Resistor: Yes
  • Thread Pitch: 1.25mm
  • Pre-Gap: 0.025" - 0.026"
  • Terminal Type: Solid

Compatible Applications

Onan-Powered Equipment: Fits Case Onan B43M, Fits Case Onan B48M, Fits Case Onan BF, Bolens Onan BF, Fits Craftsman / Sears GT18 Onan B48M

Also fits many small engines in lawn tractors, garden tractors, and utility equipment originally specifying AC Fits Delco 45L, 45LS, Fits Champion H18Y, Fits Champion RH18Y, Fits NGK B4L, Motorcraft AL82, Motorcraft AL7C, Motorcraft AS42C, or Fits Bosch WR9FC. Verify fitment against your engine model and manufacturer spark plug specification chart before ordering.

Replaces Part Number(s):

45LS, 45L-PLUG, AL7C-PLUG, AL82-PLUG, AS42C, B4L, H18Y, RH18Y, W14L-SPARK, WR9FC-PLUG

Aftermarket Interchange Numbers

Fits Champion 857, Fits Champion H18Y, Fits Champion XH18Y, AC Fits Delco 45L, AC Fits Delco 45LS, Fits NGK B4L, Fits Bosch WR9FC (Fits Bosch stock 7516), Motorcraft AL82, Motorcraft AL7C, Motorcraft AS42C, Fits Denso W14L (Fits Denso 6013), Autolite 437, Autolite 447, Autolite 216, Fits Napa X526, Prestolite 14L7, Prestolite 14L9, GM 1559483, Fits Mopar 4504290

New aftermarket replacement part - not remanufactured, not used.

Additional Information:

Thread OD: .551" (14mm), Hex: .826" (21mm), Reach: .437" (11.2mm) RH18Y

Reference Numbers:

45L-PLUG,45LS,AL7C-PLUG,AL82-PLUG,AS42C,B4L,H18Y,RH18Y,W14L-SPARK,WR9FC-PLUG
