A-H27606-AI Hub W/ Cups
A-H27606-AI Hub W/ Cups
Couldn't load pickup availability
One New Aftermarket Replacement Hub with Cups - 6-Bolt Agricultural Implement Hub
This aftermarket replacement hub with cups pre-installed is a 6-bolt agricultural implement hub designed for use on a wide range of farm implement axle applications. Rated at 2,760 lbs. capacity, this hub fits weld-on axle spindle assemblies commonly found on planters, cultivators, field tillage equipment, and other pull-type implements. Bearing cups are pre-installed in the hub; bearing cones, seal, and cap are sold separately.
Specifications
- Bolt Pattern: 6 Bolt
- Bolt Circle Diameter: 6.00"
- Hub Pilot Diameter: 4.625"
- Capacity: 2,760 lbs. @ 20 mph
- Inner Cup: LM48510
- Outer Cup: LM67010
- Series: 709
Compatible Applications
Universal agricultural implement hub. Fits weld-on axle spindles on planters, cultivators, field cultivators, and other pull-type implements requiring a 6-bolt, 6.00" bolt circle hub. Compatible with W&A Do Alls and Orthman implements among others.
Replaces Part Number(s):
A-H27606-AI, H27606
Aftermarket Interchange Numbers
Orthman 302-204; 966169; HUB611; HUB6200; 2000-3499
New aftermarket replacement part - not remanufactured, not used.
