A-C6190-12-12-W-AI (HW-C61) Code 61 Flange Head - 90� Elbow

One New Aftermarket Replacement Code 61 Flange Head 90-Degree Elbow Hydraulic Crimp Fitting

This Code 61 flange head 90-degree elbow is a W-style (Bite-to-Wire) hydraulic crimp fitting designed for high-pressure hydraulic hose assemblies used in agricultural, construction, and industrial equipment. The W-style design features serrations inside the ferrule that bite into the hose wire reinforcement, creating a strong, leak-resistant connection. This fitting accepts a 3/4" hose ID on the stem end and terminates in a 3/4" (12) Code 61 four-bolt flange connection at the 90-degree elbow end.

Specifications

• Fitting Style: W-Style (Bite-to-Wire), Rigid
• Connection Type: Code 61 Four-Bolt Flange Head, 90-Degree Elbow
• Hose Inside Diameter: 3/4" (Dash -12)
• Flange Size: 3/4" (Dash -12)
• Part Number: A-C6190-12-12-W-AI / C6190-12-12-W
• Compatible Hose Types: SAE 100R1, 100R2, 100R12, 100R16, 100R17; 4SH and 4SP spiral hose; 1-wire and 2-wire braided hose

Compatible Applications

Suitable for hydraulic hose assemblies on agricultural tractors, construction equipment, industrial machinery, and mobile equipment requiring Code 61 four-bolt flange connections. W-style fittings are compatible with many crimp systems.

Replaces Part Number(s):

A-C6190-12-12-W-AI, C6190-12-12-W, C6190-12-12W, 6190-12-12-W

Aftermarket Interchange Numbers

Interchanges with Weatherhead 12U-G72; also interchanges with Aeroquip FJ Series, Dayco SB Series, Dayco-Eastman HY Series, Imperial-Eastman HU Series, and Weatherhead U Series fittings.

New aftermarket replacement part - not remanufactured, not used.
