A-B1CE5121-AI PLASTIC RULER-GAUGE

One New Aftermarket Replacement Plastic Ruler-Gauge / Air Gap Gauge Fits Briggs & Fits Stratton Small Gasoline Engines

This plastic ruler-gauge is a dual-purpose service tool used to set the ignition coil (armature) air gap on Fits Briggs & Fits Stratton small gasoline engines. It functions as both a standard 6-inch SAE and metric ruler and a precision thickness gauge calibrated to 0.010" (0.254 mm) -- the correct armature-to-flywheel clearance specification Fits Briggs & Fits Stratton engines. To use, loosen the armature, insert the gauge between the flywheel magnet and both legs of the armature, allow the magnet to pull the armature against the gauge, then tighten the mounting fasteners and rotate the flywheel to remove. Setting the correct air gap ensures strong, consistent spark and reliable ignition system performance.

Specifications

• Air gap thickness: 0.010" (0.254 mm)
• Length: approximately 6 inches
• Material: plastic (flexible polymer)
• Graduated in both SAE and metric units

Compatible With

Fits Briggs & Fits Stratton: For general service of small gasoline engines and related equipment. Suitable for armature air gap adjustment on Fits Briggs & Fits Stratton engines across a wide range of series, including single-cylinder and twin-cylinder models requiring a 0.010" to 0.012" armature gap setting.

Replaces Part Number(s):

CE5121, A-B1CE5121-AI

New aftermarket replacement part - not remanufactured, not used.
