A-25321-AI Lo Pressure Switch

Name: A-25321-AI Lo Pressure Switch
SKU: A-25321-AI
Price: 157.0 USD
Availability: InStock

A-25321-AI Lo Pressure Switch

$157.00 CAD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

One New Aftermarket Replacement Low Pressure Switch Fits Case IH Tractors, Combines, and Harvesters

This aftermarket replacement A/C low pressure cut-out switch protects the air conditioning compressor by monitoring refrigerant pressure on the low side of the system. When pressure drops below the threshold, the switch cuts power to the compressor, preventing damage from low refrigerant or other A/C system faults. It is a direct replacement Fits Case IH (Fits Case/International Harvester) and Fits International OEM part numbers listed below.

NOTE: Several models have serial number restrictions -- verify your serial number before ordering. 1620 (s/n JJC0032630 and later), 1640 (s/n JJC0034705 and later), 1660 (s/n JJC0038346), 1670 (s/n JJC0080540 and later), 1680 (s/n JJC0045689 and later), 1822 (s/n JJC0012691 and later), 1844 (With Navistar Engine, s/n JJC0002462 and later), 4000 (s/n 4501 and later), 5000 (s/n 1901 and later), Fits International 915 (s/n 8001 and later).

Specifications

Switch Type: Normally Closed
Thread Size: 0.438 in. (11.125 mm) x 20 Thread
Opens at: 15 PSI
Closes at: 6 PSI

Compatible Models

Fits Case IH Tractors: 485, 585, 595, 685, 695, 786, 885, 886, 895, 986, 1086, 1486, 1586, Hydro 186, 3088, 3288, 3388, 3488, 3588, 3688, 3688HC, 3788, 4366, 4386, 4568, 4586, 4786, 5088, 5288, 5488, 6388, 6588, 6788, 7288, 7488

Fits Case IH Combines: 1420, 1440, 1460, 1480, 1620 (s/n JJC0032630-later), 1640 (s/n JJC0034705-later), 1644, 1660 (s/n JJC0038346), 1666, 1670 (s/n JJC0080540-later), 1680 (s/n JJC0045689-later), 1688

Fits Case IH / Fits International Harvesters: 782, 1800, 1822 (s/n JJC0012691-later), 1844 (Navistar Engine, s/n JJC0002462-later), 2022, 2044, 2055

Fits Case IH Hay Cutting Equipment: 4000 (s/n 4501-later), 5000 (s/n 1901-later)

Fits International Combines: 715, 915 (s/n 8001-later), 1420, 1440, 1460, 1470, 1480

Replaces Part Number(s):

111267C1, 111267C3, 111267C4, 442183C1

New aftermarket replacement part - not remanufactured, not used.

Models This Part Fits:

585, 986, 3388, 1586, 3788, 1666, 786, Hydro 186, 1620, 4386, 3688, 485, 1660, 5000, 1420, 895, 1640, 715, 3288, 1480, 6788, 695, 4586, 595, 1644, 5088, 885, 6388, 1680, 886, 4366, 1688, 4786, 3488, 3088, 1460, 3688HC, 1670, 4000, 5288, 1440, 7488, 1486, 3588, 1086, 6588, 7288, 685, 5488, 4568
