9500-4 Coupler Breakaway Kit Fits Pioneer Hydraulics

One New Aftermarket Replacement Coupler Breakaway Kit for Pioneer Hydraulics Agricultural Quick Couplings

This Pioneer 9500-4 lever coupler breakaway kit is a complete clamp kit for agricultural tractor hydraulic quick coupling systems. Part of the Parker Pioneer 9200 Series, it features double shut-off, lever-activated couplers that connect and disconnect even while lines are under pressure. Valves automatically close in the event of a breakaway, preventing fluid loss and contamination. The lever locks valves in the open position to prevent flow checking and protect against hydraulic surges, and locks valves closed for easy, zero-pressure connect and disconnect. Dust cover assembly closes automatically when couplers are disconnected to keep dirt out of the coupler socket. Color-coded grips and dust covers make it easy to identify raise and lower lines at a glance.

Kit Includes

• (1) 9250 lever actuated coupler - right hand orientation, red grip
• (1) 9250 lever actuated coupler - left hand orientation, yellow grip
• (1) 9006-4 clamp assembly (steel mounting bar with heavy-duty die-cast yoke)
• (1) 9507-4-1H automatic dust cover assembly

Specifications

• Body Size: 1/2 in.
• Port End: 1/2 in.-14 NPTF female
• Maximum Operating Pressure: 3,000 PSI
• Flow Rate: 12 gal/min
• Seal Material: Nitrile
• Compatible Nipple Standard: ISO 5675 (Pioneer universal male tips / 8010 Series nipples)
• Sleeve Diameter: 1-1/2 in. push-pull type

Compatible Applications

Pioneer / Parker Hannifin: 9200 Series agricultural lever-actuated quick coupling systems. Fits agricultural tractors and mobile farm equipment using 1/2 in. body size quick couplings with 1-1/2 in. diameter push-pull type sleeves. ISO 5675 compliant - connects with all Pioneer universal male tips globally.

Replaces Part Number(s):

9500-4, 9500-4-RIL

Aftermarket Interchange Numbers

Farm-Oyl BR310211, Tisco BR9500-4, 799637

New aftermarket replacement part - not remanufactured, not used.
