3437101-JN Hella Relay-12V-60A-SPST
3437101-JN Hella Relay-12V-60A-SPST
Regular price
$143.00 CAD
Regular price
Sale price
$143.00 CAD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
One New Aftermarket Replacement Hella 12V 60A SPST Wiring Relay with Diode and Mounting Bracket
This Hella (HELLA) heavy-duty wiring relay is a Single Pole Single Throw (SPST/Form A) normally open relay rated at 12 volts and 60 amps continuous load. It features integrated diode coil suppression to eliminate voltage spikes when the relay deactivates, protecting sensitive electronic equipment in the circuit. A mounting bracket is included for secure installation. Common applications include auxiliary lighting, horns, fan motors, fuel pumps, power windows, and other high-current 12V circuits on agricultural, construction, and commercial vehicles.
Specifications
- Voltage: 12V nominal
- Contact Form: SPST / Form A (normally open)
- Continuous Amp Rating: 60A
- Coil Suppression: Diode (eliminates voltage spikes)
- Mounting Bracket: Included
- Operating / Releasing Time: 10 ms / 20 ms
- Ambient Temperature Range: -40 degrees C to +85 degrees C
- Contact Material: AgSnO2
- Coil Resistance: 85 Ohm +/- 10%
- Pin-out: B3
- Terminals: Blade type (ISO 8092)
Replaces Part Number(s):
3437101, 003437101
Aftermarket Interchange Numbers
HLA-003437101 (Summit Racing), 3RA 003 437-101
New aftermarket replacement part - not remanufactured, not used.
