Clutch Kit Disc / Pulley Repair Kit Fits John Deere Replaces 14H862

Clutch Kit Disc / Pulley Repair Kit Fits John Deere Replaces 14H862

$152.00 CAD
$152.00 CAD
Sale Sold out
Shipping calculated at checkout.
One New Aftermarket Clutch Kit Disc / Pulley Repair Kit

Tech Info:
 -(1) Facing Clutch Pulley
 -10" disc outside diameter
 -0.393" thick
 -Replaces Part Numbers: AA5082R, AA6129
 -
 -(2) Facing Clutch Discs
 -10" outside diameter
 -6-3/4" inside diameter
 -0.150" thick
 -The side with the grooves faces the driving disc
 -1-5/8" lining width
 -Replaces Part Numbers: R90215, C614R
 -
 -(1) Brake Pad Pulley
 -Non-asbestos lining with countersunk brass rivets
 -Replaces Part Numbers: AB4748R, AF4748R, RE29790
 -
 -(3) Clutch Disc Adjusting Springs
 -1.915" long
 -0.740" outside diameter
 -0.500" inside diameter
 -0.120" wire thickness
 -The clutch disc adjusting spring mounts to the outer cast iron adjusting disc
 -3 springs used per tractor
 -Replaces Part Numbers: A352R
 -
 -(3) Clutch Adjusting Nuts
 -9/16" - 18 NF
 -Grade 5
 -Slotted hex nut, 9/16"
 -3 used per tractor; sold individually
 -Replaces Part Numbers: 14H862, AD2850R, D2789R, R20228
 -
 -(3) Clutch Pressure Plate Spring (Fits Belleville) Washers
 -0.572" inside diameter
 -0.937" outside diameter
 -0.035" thick
 -Spring steel
 -Torque initially to 15 FT pounds, then adjust as needed
 -Use to smooth out the hand clutch engagement
 -3 used per tractor
 -Replaces part Numbers: JDS1626

Made to Fits John Deere:
 Tractor Models: 520, 530, 620, 630, 720, 730
 Replaces Part Number(s): AA5082R, AA6129, JDS1626, 14H862, R20228, D2789R, AD2850R, A352R, AB4748R, AF4748R, RE29790, R90215, C614R

Models This Part Fits:

520, 530, 730, 720, 630, 620

Additional Information:

(1) Facing Clutch Pulley 10" disc outside diameter 0.393" thick Replaces Part Numbers: AA5082R, AA6129 (2) Facing Clutch Disc 10" outside diameter (OD) 6-3/4" inside diameter (ID) 0.150" thick The side with the grooves faces the driving disc 1-5/8" lining width Replaces Part Numbers: R90215, C614R (1) Brake Pad Pulley Non-asbestos lining with countersunk brass rivets Replaces Part Numbers: AB4748R, AF4748R, RE29790 (3) Clutch Disc Adjusting Spring 1.915" long 0.740" outside diameter 0.500" inside diameter 0.120" wire thickness The clutch disc adjusting spring mounts to the outer cast iron adjusting disc 3 springs used per tractor Replaces Part Numbers: A352R (3) Clutch Adjusting Nut 9/16" - 18 NF Grade 5 Slotted hex nut, 9/16" 3 used per tractorReplaces Part Numbers: 14H862, AD2850R, D2789R, R20228 (3) Clutch Pressure Plate Spring (Belleville) Washer 0.572" inside diameter 0.937" outside diameter 0.035" thick Spring steel Torque initially to 15 FT pounds, then adjust as needed Use to smooth out the hand clutch engagement 3 used per tractor Replaces part Numbers: JDS1626

Reference Numbers:

AA5082R, AA6129, JDS1626, 14H862, R20228, D2789R, AD2850R, A352R, AB4748R, AF4748R, RE29790, R90215, C614R
