One New Aftermarket Replacement Ring-Backup for Caterpillar (Cat) Excavators and Mobile Hydraulic Power Units
This PTFE backup ring (Cat part 126-4004) is used in the hydraulic travel motor assembly on large Caterpillar excavators and mobile hydraulic power units. Backup rings work in tandem with O-rings to prevent seal extrusion under high hydraulic pressure, maintaining fluid integrity and extending the service life of the hydraulic system.
Specifications
- Inside Diameter (ID): 241.3 mm (9.5 in)
- Outside Diameter (OD): 243.74 mm
- Axial Width: 3.02 mm
- Radial Height: 1.22 mm
- Material: PTFE (Polytetrafluoroethylene) - glass-filled plastic
Compatible Models
Caterpillar Excavators: 330C, 330D L, 330D MH, 345B II, 345B II MH, 345C, 345C L, 345C MH, 345D, 345D L, 345D L VG, 349D, 349D L, 349E, 349E L, 349E L VG, 349F L, 374D L, 374F L
Caterpillar Mobile Hydraulic Power Units: 345C L, 349E L HVG
Replaces Part Number(s):
1264004, 126-4004
New aftermarket replacement part - not remanufactured, not used.
