1142474 Fan Fits Caterpillar Models
1142474 Fan Fits Caterpillar Models
Regular price
$101.00 CAD
Regular price
Sale price
$101.00 CAD
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
One New Aftermarket Replacement Engine Cooling Fan for Caterpillar (Cat) Excavators
This aftermarket replacement fan blade (114-2474 / 1142474) is a 7-blade suction-type engine cooling fan used in the engine cooling system of Caterpillar compact and mid-size excavators. It mounts via a 4-stud pattern and circulates air through the radiator and coolant assembly to maintain proper engine operating temperature on 3054, 3054E, 3056, 3056E, C4.4, and C6.6 series engines.
Specifications
- Type: 7-blade suction fan
- Mount: 4-stud
- Rotational Diameter: 22 in (558 mm)
- Overall Dimensions: 22.44 x 22.44 x 2.76 in
- Weight: 4 lbs
Compatible Models
Caterpillar Excavators: 312, 312B, 312B L, 315, 315B L, 317, 317N
Caterpillar Engines: 3054, 3054E, 3056, 3056E, C4.4, C6.6
Replaces Part Number(s):
1142474, 114-2474, CA1142474
New aftermarket replacement part - not remanufactured, not used.
